Set Plug Gages for Calibrating Ring Gages

ALAMEDA

1" 8 UNC 2A SET THREAD PLUG GAGE 1.0 GO ONLY P.D. = .9188 1.00 1.000 QUALITY

TRW

5/16 18 UNC 2A LEFT HAND SET THREAD PLUG GAGE .3125 GO NO GO PDS= .2752 & .2712 - CS7603FC

S.C.C.

5 44 NF 2 SET THREAD PLUG GAGE #5 .125 GO NO GO P.D.'S = .1102 & .1079 .1250

PMC

1 5/16 18 UNEF 3A HILO SPECIAL SET THREAD PLUG GAGE 1.3125 GO ONLY P.D. = 1.2764

THE JOHNSON GAGE CO.

1 1/2 14 UNS 2A SET THREAD PLUG GAGE 1.5 GO NO GO P.D.'S = 1.4520 & 1.4465 NS-2A

PENNOYER-DODGE

1 3/4 12 UN 3A SET THREAD PLUG GAGE 1.75 GO ONLY P.D. = 1.6959 1.750 QUALITY

SCHRILLO

10 24 NC 5 W SET THREAD PLUG GAGE #10 .190 GO NO GO P.D.'S = .1643 & .1638

G.A. CO.

1/4 20 NC 3 SPL DOUBLE LEAD SET THREAD PLUG GAGE .25 GO NO GO= .2145 .2119 2-STR

G.A. CO.

1/4 20 UNC 3A QUAD LEAD SET THREAD PLUG GAGE .25 GO NO GO P.D.'S = .2175 & .2147

PRATT & WHITNEY

2 5/8 16 NS SET THREAD PLUG GAGE 2.625 GO ONLY P.D. = 2.5800 2.6250 INSPECTION

BURDICK

1 1/2 40 NS SET THREAD PLUG GAGE 1.5 GO ONLY P.D. = 1.4838 1.50 1.500 1.5000

1 1/8 16 UN 2A SPECIAL SET THREAD PLUG GAGE 1.125 GO NO GO PD'S= 1.0824 & 1.0784
