Set Plug Gages for Calibrating Ring Gages

PRATT & WHITNEY

9/32 32 NS LEFT HAND SET THREAD PLUG GAGE .2813 GO NO GO PD'S = .2600 & .2582 LH

7/8 14 UNF 2A SPECIAL SET THREAD PLUG GAGE .875 GO NO GO P.D.'S = .8260 & .8206

3/4 10 UNS 3A SET THREAD PLUG GAGE .75 NO GO ONLY P.D. = .6806 3/4-10 SETTING

P.D. CO.

1/2 20 NF SET THREAD PLUG GAGE .5 GO ONLY P.D. = .4675 QUALITY 1/2-20 CHECK TOOL

METRO

5/16 24 SPECIAL SET THREAD PLUG GAGE .3125 NO GO ONLY P.D. = .2780 5/16-24 TOOL

CADILLAC GAGE CO.

3/8 16 NC SET THREAD PLUG GAGE .375 GO ONLY P.D. = .3444 QUALITY 3/8-16 TOOL

HUECKSTAEDT

5/16 56 NS 3A LEFT HAND SET THREAD PLUG GAGE .3125 GO ONLY P.D. = .2989 L.H.

HY PRO

12 24 UNC 2A SET THREAD PLUG GAGE #12 .216 GO NO GO P.D.'S = .1879 & .1845 CHECK

5/16 24 UNF 2A SET THREAD PLUG GAGE .3125 GO NO GO P.D.'S = .2843 & .2806 CHECK - DS0930BU

PENNOYER - DODGE CO.

4 3/8 16 HILO SET THREAD PLUG GAGE 4.375 GO NO GO P.D.'S = 4.3344 & 4.3278 TOOLS

MLS

.480 32 UNS 2A SET THREAD PLUG GAGE 0.48 GO NO GO P.D.'S = .4587 & .4552 CHECK

WAFCO

.277 40 UNS 2A SET THREAD PLUG GAGE 0.277 GO NO GO P.D.'S= .2599 & .2570 .277-40
