Set Plug Gages for Calibrating Ring Gages

GAGE ASSEMBLY CO.

3/8 24 UNF 2A SPECIAL SET THREAD PLUG GAGE .375 GO NO GO P.D.'S = .3431 & .3415

VERMONT

7/16 20 UNF 2A VERMONT SET THREAD PLUG GAGE .4375 GO NO GO P.D.'S= .4037 & .3995

ALAMEDA

9/16 24 UNEF 2A SET THREAD PLUG GAGE .5625 GO NO GO P.D.'S = .5342 & .5303 CHECK - JF1060SL

GAGE ASSEMBLY CO.

1/2 20 UNF 2A SPECIAL SET THREAD PLUG GAGE .5 GO NO GO PD'S = .4634 & .4603 SPL.

12 40 UNS 2A PREPLATE SET THREAD PLUG GAGE #12 .216 GO NO GO PDS = .1967 & .1947

3/8 32 UNEF 2A PREPLATE SET THREAD PLUG GAGE .375 GO NO GO P.D.'S= .3521 & .3495

SOUTHERN GAGE CO.

9/16 27 UNS 2A SET THREAD PLUG GAGE .5625 GO NO GO P.D.'S= .5345 & .5320 9/16-27

GAGE ASSEMBLY CO.

1/2 20 NF 2 SPECIAL SET THREAD PLUG GAGE .5 GO NO GO P.D.'S = .4665 & .4639 SPEC

3/8 16 UNC 2A PREPLATE SET THREAD PLUG GAGE .375 GO NO GO P.D.'S = .3323 & .3283

.354 32 NS 2 DOUBLE LEAD SET THREAD PLUG GAGE 0.354 GO NO GO PD'S= .3337 & .3313

GODWIN

21/32 12 ACME 2G LEFT HAND SET THREAD PLUG GAGE .656 GO NO GO PDS= .6080 & .5941

CADILLAC GAGE CO.

1/2 20 NS SET THREAD PLUG GAGE .5 GO NO GO P.D.'S = .4721 & .4708 SETTING TOOL
