Set Plug Gages for Calibrating Ring Gages

SHEFFIELD

5/8 24 NEF 2 SET THREAD PLUG GAGE .625 GO NO GO P.D.'S = .5939 & .5898 SETTING

METRO

27/32 24 NS 2 SET THREAD PLUG GAGE .84375 GO NO GO P.D.S = .8166 & .8121 SETTING

HUECKSTAEDT

1 1/8 24 UNS 3A SET THREAD PLUG GAGE 1.125 GO NO GO P.D.'S = 1.0979 & 1.0948

METRO

1 13/16 16 NS 3 SET THREAD PLUG GAGE 1.8125 GO NO GO P.D.'S = 1.7719 & 1.7677

PARCEL & BAUER

1 5/16 18 NS SET THREAD PLUG GAGE 1.3125 GO NO GO P.D.'S = 1.2784 & 1.2764 TOOL

PARCEL & BAUER

11/16 32 SET THREAD PLUG GAGE .6875 GO NO GO P.D.'S = .6672 & .6649 SETTING TOOL

CADILLAC GAGE CO.

23/32 48 NS 2 SET THREAD PLUG GAGE .71875 GO NO GO P.D.'S= .7052 & .7015 SETTING

METRO

27/32 24 NS 2 SET THREAD PLUG GAGE .84375 GO NO GO P.D.'S= .8166 & .8125 SETTING

CADILLAC GAGE CO.

1 7/8 12 NS SET THREAD PLUG GAGE 1.875 GO NO GO P.D.'S = 1.8159 & 1.8113 QUALITY

VERMONT GAGE

1 1/2 24 UNS 2A SET VERMONT THREAD PLUG GAGE 1.5 GO NO GO PD'S = 1.4716 & 1.4672

SOUTHERN GAGE CO.

1" 20 NEF SPECIAL SET THREAD PLUG GAGE 1.0 GO NO GO P.D.'S = .9724 & .9702 TOOLS

WESTPORT

1" 14 UNS 2A SET THREAD PLUG GAGE 1.0 GO NO GO P.D.'S .9519 & .9463 1"-14 UNS-2A - CH2074BURL
