Set Plug Gages for Calibrating Ring Gages

PRATT & WHITNEY

2" 4 ACME SET THREAD PLUG GAGE 2.0 4. GO NO GO P.D.'S = 1.8750 & 1.8673 CHECK - DW31597OB4

REGAL

1 15/16 16 UN 2A SET THREAD PLUG GAGE 1.9375 GO NO GO P.D.'S = 1.8953 & 1.8899 - DW31596OB4

SCHRILLO

CERTIFIED 3 11/16 12 UNS 3A SET THREAD PLUG GAGE 3.6875 GO NO GO = 3.6334 3.6286 - DW31166TLC

11/16 20 UNS 3A PREPLATE SET THREAD PLUG GAGE .6875 GO ONLY P.D. = .6465 CHECK - DW31570LVR

PMC

13/16 28 UN 2A HILO SET THREAD PLUG GAGE .8125 GO NO GO P.D.'S = .7881 & .7843 - DW31568LVR

9/16 20 UN 2A SET THREAD PLUG GAGE .5625 GO NO GO P.D.'S = .5287 & .5245 CHECK - DW31567LVR

CERTIFIED M14 X 1.5 6g SET THREAD PLUG GAGE 14 GO NO GO PD'S = 12.994 & 12.854 - DW31555TLC

CERTIFIED M20 X 1.5 6g SET THREAD PLUG GAGE 20 GO NO GO PD'S = 18.994 & 18.854 - DW31554TLC

SCC

CERTIFIED 0 80 UNF 2A SET THREAD PLUG GAGE #0 .060 GO NO GO PDS= .0514 & .0496 - DW31553TLC

PRATT & WHITNEY

CERTIFIED 3 56 NF 2A SET THREAD PLUG GAGE #3 .099 GO NO GO PD'S = .0867 & .0845 - DW31552TLC

SWANSON

CERTIFIED M6 X 1 6g LEFT HAND SET THREAD PLUG GAGE 6 1.0 GO NO GO = 5.324 5.212 - DW31550TLC

GREENFIELD

CERTIFIED 8 32 UNC 3A SET THREAD PLUG GAGE #8 .164 GO NO GO PDS= .1437 & .1415 - DW31549TLC
