Set Plug Gages for Calibrating Ring Gages

LC

7/16 20 UNS PREPLATE SET THREAD PLUG GAGE .4375 GO ONLY P.D. = .4027 INSPECTION - DW27699RD

SHEFFIELD

1 1/8 8 N 7 SET THREAD PLUG GAGE 1.125 1.1250 GO ONLY P.D. = 1.0414 INSPECTION - DW27678RD

ALAMEDA

.150 80 UNS 2A SET THREAD PLUG GAGE .15 .1500 GO NO GO P.D.'S = .1413 & .1392 - DW27677RD

DOALL

12 28 NF 3 SET THREAD PLUG GAGE #12 .216 .2160 GO NO GO P.D.'S = .1928 & .1906 - DW27676RD

SHEFFIELD

1 3/8 8 N SET THREAD PLUG GAGE 1.375 1.3750 NO GO ONLY P.D. = 1.2852 INSPECTION - DW27686RD

WOODWORTH

12 28 NS SET THREAD PLUG GAGE #12 .216 GO NO GO P.D.'S = .1895 & .1870 FULL FORM - DW27675RD

SHEFFIELD

1 1/8 8 N 2 SET THREAD PLUG GAGE 1.125 1.1250 NO GO ONLY P.D. = 1.0359 FULL FORM - DW27674RD

GTD

1" 8 NC 7 SET THREAD PLUG GAGE 1.0 1.00 1.000 1.0000 GO ONLY P.D. = .9166 CHECK - DW27673RD

SHEFFIELD

7/8 9 NC 2 SET THREAD PLUG GAGE .875 .8750 NO GO ONLY P.D. = .7658 INSPECTION - DW27688RD

WESTPORT

1/2 12 UN 2A DOUBLE LEAD SET THREAD PLUG GAGE .5 .50 NO GO ONLY P.D. = .4393 - DW27641RD

HEMCO

.211 28 UNS 4 START SET THREAD PLUG GAGE .2110 GO NO GO P.D.'S = .2080 & .2040 - DW27648RD

GTD

1 5/16 12 NS 2 SET THREAD PLUG GAGE 1.3125 GO NO GO = 1.2610 & 1.2554 FULL FORM - DW27640RD
