Set Plug Gages for Calibrating Ring Gages

3/4 27 NS 2 SET THREAD PLUG GAGE .75 GO NO GO P.D.'S = .7259 & .7218 FULL FORM - DW27344RD

HANSON WHITNEY

5/8 18 NF 3 SET THREAD PLUG GAGE .625 .6250 GO NO GO P.D.'S = .5889 & .5859 - DW27310RD

7/16 20 NF 3 SET THREAD PLUG GAGE .4375 GO NO GO P.D.'S = .4050 & .4024 CHECK - DW27309RD

9/16 18 NF 3 SET THREAD PLUG GAGE .5625 GO NO GO P.D.'S = .5264 & .5234 CHECK - DW27311RD

HANSON WHITNEY

5/8 24 NEF 3 SET THREAD PLUG GAGE .625 .6250 GO NO GO P.D.'S = .5979 & .5950 - DW27308RD

DOALL

1.305 32 NS 3 SET THREAD PLUG GAGE 1.3050 GO NO GO P.D.'S = 1.2847 & 1.2807 - DW27303RD

7/8 18 NS 3 SET THREAD PLUG GAGE .875 .8750 GO NO GO P.D.'S = .8389 & .8353 - DW27300RD

WEST & DODGE

1 3/4 12 N 3 SET THREAD PLUG GAGE 1.75 1.750 GO NO GO P.D.'S = 1.6959 & 1.6913 - DW27285AP4

1.7987 20 UNF 2A SET THREAD PLUG GAGE GO NO GO P.D.'S = 1.7647 & 1.7599 CHECK - DW27284AP4

CERTIFIED 1 3/4 12 UN 2A SET THREAD PLUG GAGE 1.75 GO NO GO = 1.6941 & 1.6881 - DW27276TLC

1 27/32 20 UNS 2A SET THREAD PLUG GAGE 1.84375 1.8437 GO NOGO PDS= 1.8097 1.8049 - DW27282AP4

GSG

1 5/8 12 UNS 2A SET THREAD PLUG GAGE 1.625 GO NO GO P.D.'S = 1.5709 & 1.5645 - DW27281AP4
