Set Plug Gages for Calibrating Ring Gages

GSG

1/4 16 ACME 3G SET THREAD PLUG GAGE .25 .250 GO ONLY P.D. = .2158 INSPECTION - DW27058LVR

VERMONT GAGE

5/16 18 UNC 2A DOUBLE LEAD VTG SET THREAD PLUG GAGE .3125 GO NO GO = .2752 .2712 - DW27071LVR

M15 X 1 6G METRIC SET THREAD PLUG GAGE 15 1.0 GO NO GO P.D.'S = 14.324 & 14.206 - DW27069LVR

LEADER CORP

1.967 18 N 3 N10 LOCKNUT SET THREAD PLUG GAGE GO NO GO P.D.'S = 1.9309 & 1.9264 - DW27053LVR

VERMONT GAGE

M5 X .5 6g METRIC VERMONT SET THREAD PLUG GAGE 5 0.5 NO GO ONLY P.D. = 4.580 - DW27052LVR

G.A. CO.

M8 X 1 6g METRIC SET THREAD PLUG GAGE 8 1.0 GO NO GO P.D.'S = 7.324 & 7.212 - DW27051LVR

GSG

3/8 10 ACME 2G LEFT HAND SET THREAD PLUG GAGE .375 GO ONLY P.D. = .3201 L.H. - DW27044LVR

VERMONT GAGE

5 40 UNC 2A VERMONT SET THREAD PLUG GAGE #5 .125 GO NO GO P.D.'S = .1080 & .1054 - DW27042LVR

G.A. CO.

BUDGET M33 X 2 6g METRIC SET THREAD PLUG GAGE 33 2.0 NO GO ONLY P.D. = 31.531 - DW27041LVR

M16 X 1.5 4h METRIC SET THREAD PLUG GAGE 16 GO NO GO P.D.'S = 15.026 & 14.936 - DW27012LVR

HEMCO

M12 X 1.25 6g METRIC SET THREAD PLUG GAGE 12 GO NO GO P.D.'S = 11.160 & 11.028 - DW27007LVR

VERMONT GAGE

M18 X 1 6g VERMONT SET THREAD PLUG GAGE 18 1.0 GO NO GO P.D.'S = 17.324 & 17.206 - DW27011LVR
