Set Plug Gages for Calibrating Ring Gages

GTD

11/16 27 NS 1 SET THREAD PLUG GAGE .6875 GO NO GO P.D.'S = .6621 & .6564 CHECK - DW26044BL3

SCHRILLO

CERTIFIED 5" 12 UN 3A SET THREAD PLUG GAGE 5.0 GO NO GO PD'S = 4.9459 & 4.9409 - DW26947TLC

CERTIFIED 13/16 32 UN 2A SET THREAD PLUG GAGE .8125 GO NO GO PDS= .7911 & .7875 - DW26941TLC

MERCURY GAGE

CERTIFIED 1 1/16 16 UN 2A SET THREAD PLUG GAGE 1.0625 GO NO GO = 1.0204 1.0154 - DW26940TLC

PACIFIC GAGE

CERTIFIED 3 3/8 16 N 3 SET THREAD PLUG GAGE 3.375 GO NO GO PDS= 3.3344 & 3.3296 - DW26927TLC

HEMCO

CERTIFIED 3" 16 UNJ 3A SET THREAD PLUG GAGE 3.0 GO NO GO PD'S = 2.9594 & 2.9552 - DW26922TLC

ALAMEDA

CERTIFIED 1 1/8 12 UNF 2A SET THREAD PLUG GAGE 1.125 GO NO GO = 1.0691 & 1.0631 - DW26895TLC

7/16 20 UNJF 3A SPECIAL SET THREAD PLUG GAGE .4375 GO ONLY PD = .4035 FULL FORM - DW26894LVR

GSG

3/8 24 UNJF 3A SPECIAL SET THREAD PLUG GAGE .375 GO ONLY P.D. = .3465 FULL FORM - DW26893LVR

P & W

1" 11 1/2 ANPT PIPE SET THREAD PLUG GAGE 1.0 1.00 1.000 1.0000 NPT MASTER L1 L2 - DW26891LVR

GSG

7/16 20 UNJF 3A SPECIAL SET THREAD PLUG GAGE .4375 GO ONLY PD = .4035 FULL FORM - DW26892LVR

WOODWORTH

CERTIFIED 9/16 32 NS 2 SET THREAD PLUG GAGE .5625 GO NO GO = .5422 .5382 CHECK - DW26870TLC
