Set Plug Gages for Calibrating Ring Gages

6 1/2 12 UN 2A SET THREAD PLUG GAGE 6.5 6.50 6.500 6.5000 GO ONLY P.D. = 6.4438 - DW26159RD

LC

3.137 12 N3 AN16 LOCKNUT SET THREAD PLUG GAGE 3.1370 GO ONLY P.D. = 3.0829 CHECK - DW26146RD

GREENFIELD

CERTIFIED M5 X .8 8g SET THREAD PLUG GAGE 5 0.8 GO NO GO P.D.'S = 4.456 & 4.361 - DW26103TLC

VAN KEUREN

CERTIFIED 4 48 UNF 2A SET THREAD PLUG GAGE #4 .112 GO NO GO PDS= .0978 & .0954 - DW26104TLC

VAN KEUREN

CERTIFIED 2" 16 UN 3A SET THREAD PLUG GAGE 2.0 GO NO GO PD'S = 1.9594 & 1.9554 - DW26102TLC

1 3/4 12 UN SPL SPECIAL SET THREAD PLUG GAGE 1.75 GO NO GO PDS= 1.6935 & 1.6829 - DW26091BL3

SCHRILLO

CERTIFIED 3 3/4 16 UN 2A SET THREAD PLUG GAGE 3.75 GO NO GO = 3.7077 & 3.7019 - DW26080TLC

CERTIFIED 1" 20 UNEF BEFORE PLATE SET THREAD PLUG GAGE 1.0 GO NO GO = .9629 .9596 - DW26066TLC

WESTPORT

CERTIFIED M32 X 1.5 6g SET THREAD PLUG GAGE 32 GO NO GO PD'S = 30.994 & 30.844 - DW25982TLC

LC

1 3/8 12 UNF 2A LEFT HAND SET THREAD PLUG GAGE 1.375 GO NO GO = 1.3190 1.3127 - DW25970TLC

TRW

CERTIFIED 5/8 18 UNF 2A SET THREAD PLUG GAGE .625 GO NO GO PD'S = .5875 & .5828 - DW25966TLC

NORTH AMERICAN

10 32 UNF 2A LEFT HAND SET THREAD PLUG GAGE #10 .190 GO NO GO PDS= .1688 & .1658 - DW25927BH3
