Set Plug Gages for Calibrating Ring Gages

TRW

10 24 UNC SPEC SET THREAD PLUG GAGE #10 .190 GO NO GO P.D.'S = .1607 & .1584 - DW25928BH3

SWANSON

1/4 32 UNEF 2A LEFT HAND SET THREAD PLUG GAGE .25 GO NO GO PD'S = .2287 & .2255 - DW25925BH3

TRW

10 32 UNF W BEFORE PLATE SET THREAD PLUG GAGE #10 .190 NO GO ONLY P.D. = .1649 - DW25915BH3

SWANSON

3/8 16 UNC 2A PREPLATE SET THREAD PLUG GAGE .375 GO NO GO P.D.'S = .3324 & .3273 - DW25913BH3

7/16 20 UNF SPL SPECIAL SET THREAD PLUG GAGE .4375 GO NO GO PD'S = .4017 & .3975 - DW25907BH3

G.A. CO.

M8 X 1.25 BEFORE PLATE SET THREAD PLUG GAGE 8 GO ONLY P.D. = 7.110 METRIC CHECK - DW25912BH3

TRW

1/4 32 UNEF 2A W BEFORE PLATE SET THREAD PLUG GAGE .25 GO NO GO = .2275 & .2243 - DW25904BH3

SWANSON

1/4 32 UNEF 2A LEFT HAND PREPLATE SET THREAD PLUG GAGE .25 GO NO GO = .2277 .2245 - DW25908BH3

PIONEER

3/8 16 UN 2A LEFT HAND SET THREAD PLUG GAGE .375 GO NO GO P.D.'S = .3331 & .3287 - DW25905BH3

M10 X 1.5 6g PREPLATE DOUBLE LEAD SET THREAD PLUG GAGE 10 GO NO GO = 8.890 8.763 - DW25903BH3

TRW

3/4 24 UNS 2A W BEFORE PLATE SET THREAD PLUG GAGE .75 GO NO GO = .7166 & .7127 - DW25902BH3

G.A. CO.

M8 X 1.25 PREPLATE SET THREAD PLUG GAGE 8 GO NO GO P.D.'S = 7.087 & 6.985 METRIC - DW25885BH3
