Set Plug Gages for Calibrating Ring Gages

HEMCO

CERTIFIED 1 5/16 18 UNEF 2A BP SET THREAD PLUG GAGE 1.3125 GO NOGO 1.2689 1.2668 - DW25825TLC

BATH

CERTIFIED 2 3/8 12 NC SET THREAD PLUG GAGE 2.375 GO ONLY P.D. = 2.3209 UN-3A - DW25762TLC

VAN KEUREN

CERTIFIED 1 1/4 8 UN 2A SET THREAD PLUG GAGE 1.25 GO NO GO PDS= 1.1667 & 1.1597 - DW25761TLC

GSG

1 1/4 18 UNEF SPL 2A SPECIAL SET THREAD PLUG GAGE 1.25 NO GO ONLY P.D. = 1.2045 - DW25743LVR

M25 X 1.5 6g METRIC SET THREAD PLUG GAGE 25 NO GO ONLY P.D. = 23.844 INSPECTION - DW25754LVR

MERCURY GAGE

CERTIFIED 7/8 14 UNJF 3A SET THREAD PLUG GAGE .875 GO NO GO PDS= .8286 & .8245 - DW25753TLC

HARRIS

CERTIFIED 7/8 9 UNC 2A SET THREAD PLUG GAGE .875 GO NO GO PD'S = .8009 & .7946 - DW25752TLC

GSG

1 3/8 16 UN 2A SET THREAD PLUG GAGE 1.375 1.3750 GO ONLY P.D. = 1.3329 CHECK - DW25742LVR

PRATT & WHITNEY

3 15/32 12 UNS 3A SET THREAD PLUG GAGE 3.46875 NO GO ONLY P.D. = 3.4093 CHECK - DW25697RD

EFCO

7/16 14 UNC 1A SET THREAD PLUG GAGE .4375 GO NO GO P.D.'S = .3897 & .3826 CHECK - DW25736BI3

EFCO

3/8 27 NS 2A SET THREAD PLUG GAGE .375 .3750 GO NO GO P.D.'S = .3498 & .3462 - DW25740BI3

EFCO

3/4 10 NA 2G ACME SET THREAD PLUG GAGE .75 .750 GO NO GO P.D.'S = .6931 & .6784 - DW25738BI3
