Set Plug Gages for Calibrating Ring Gages

EFCO

.576 24 NS 2A SET THREAD PLUG GAGE .5760 GO NO GO P.D.'S = .5477 & .5437 CHECK - DW25702BI3

EFCO

7/16 14 NS SET THREAD PLUG GAGE .4375 GO NO GO P.D.'S = .3840 & .3820 CHECK - DW25701BI3

PRATT & WHITNEY

CERTIFIED 3/4 20 UNEF 2A SET THREAD PLUG GAGE .75 GO NO GO PD'S = .7162 & .7118 - DW25680TLC

LINCOLN GAGE

CERTIFIED M14 X 2 6g SET THREAD PLUG GAGE 14 2.0 GO NO GO PDS= 12.663 & 12.503 - DW25679TLC

DETROIT

1 3/4 12 N SET THREAD PLUG GAGE 1.75 1.750 1.7500 GO ONLY P.D. = 1.6959 UN-3A - DW25664BF3

VERMONT GAGE

2 1/8 12 UN 2A VERMONT SET THREAD PLUG GAGE 2.125 GO NO GO PDS= 2.0691 & 2.0630 - DW25660BF3

1 1/4 12 NF 3 BEFORE PLATE SET THREAD PLUG GAGE 1.25 GO NO GO = 1.1949 & 1.1909 - DW25657BF3

WESTPORT

12 40 UNS 2A SET THREAD PLUG GAGE #12 .216 .2160 GO NO GO P.D.'S = .1989 & .1960 - DW25643BF3

WESTPORT

M1.6 X .35 6g SET THREAD PLUG GAGE 1.6 0.35 GO NO GO P.D.'S = 1.354 & 1.291 - DW25602LVR

ALAMEDA

M8 X 1.25 6g PREPLATE SET THREAD PLUG GAGE 8 GO NO GO P.D.'S = .2818 & .2773 - DW25585BF3

WESTPORT

M6 X 1 6h PREPLATE SET THREAD PLUG GAGE 6 1.0 GO NO GO P.D.'S = 5.266 & 5.161 - DW25583BF3

WESTPORT

M6 X 1 6g PREPLATE SET THREAD PLUG GAGE 6 1.0 GO NO GO P.D.'S = 5.308 & 5.204 - DW25584BF3
