Set Plug Gages for Calibrating Ring Gages

VERMONT GAGE

CERTIFIED 7/8 14 UNF 2A VERMONT SET THREAD PLUG GAGE .875 GO ONLY P.D. = .8216 - DW25113BA3

VERMONT

1" 14 UNS 2A VERMONT SET THREAD PLUG GAGE 1.0 1.00 1.000 NO GO ONLY P.D. = .9467 - DW25094LVR

DOALL

7/16 20 UNS 3A SPECIAL SET THREAD PLUG GAGE .4375 GO NO GO PD'S = .4020 & .3989 - DW24996LVR

23/32 32 CLASS 2 BEFORE PLATE SET THREAD PLUG GAGE .71875 GO NO GO = .6964 .6935 - DW24935RD

GENERAL

9/16 24 NEF 2A BEFORE PLATE SET THREAD PLUG GAGE .5625 GO NO GO = .5326 & .5295 - DW24928RD

3/4 32 UNS 2 SET THREAD PLUG GAGE .75 .750 .7500 GO NO GO P.D.'S = .7297 & .7250 - DW24929RD

DETROIT

3/4 16 NF 2 SET THREAD PLUG GAGE .75 .750 .7500 GO ONLY P.D. = .7094 UNF-3A - DW24930RD

MERCURY GAGE

1/4 28 UNF 3A SET THREAD PLUG GAGE .25 .250 GO NO GO P.D.'S = .2268 & .2243 - DW24931RD

VERMONT GAGE

25/32 40 NS VERMONT SET THREAD PLUG GAGE .78125 GO NO GO P.D.'S = .7650 & .7616 - DW24934RD

3/4 20 NEF 2 SET THREAD PLUG GAGE .75 .750 .7500 GO NO GO P.D.'S = .7175 & .7129 - DW24927RD

GEN GAGE

1/2 20 UNF 2A BEFORE PLATE SET THREAD PLUG GAGE .5 GO NO GO PD'S = .4646 & .4611 - DW24936RD

5/8 32 BEFORE PLATE SET THREAD PLUG GAGE .625 GO NO GO P.D.'S = .6031 & .6002 - DW24937RD
