Set Plug Gages for Calibrating Ring Gages

HEMCO

CERTIFIED 4 1/2 12 UN 2A SET THREAD PLUG GAGE 4.5 GO NO GO PDS= 4.4439 & 4.4374 - DW24067LVR

CERTIFIED 3/8 16 UNC 2A SET THREAD PLUG GAGE .375 GO NO GO PD'S = .3331 & .3287 - DW24065LVR

GREENFIELD

CERTIFIED 3/8 27 UNS 2A SET THREAD PLUG GAGE .375 GO NO GO PD'S = .3498 & .3462 - DW24064LVR

CERTIFIED 4" 16 UN 2A SET THREAD PLUG GAGE 4.0 GO NO GO PD'S = 3.9576 & 3.9517 - DW24066LVR

PONAM

1 1/2 16 UNJ 3A BEFORE PLATE SET THREAD PLUG GAGE 1.5 NO GO ONLY P.D. = 1.4547 - DW23957RD

PENNOYER DODGE

1 1/2 8 UNJ 3A BEFORE PLATE SET THREAD PLUG GAGE 1.5 GO NO GO = 1.4164 & 1.4125 - DW23955RD

PRATT & WHITNEY

1" 20 N SET THREAD PLUG GAGE 1.0 1.00 1.000 GO NO GO P.D.'S = .9675 & .9624 - DW23944RD

PONAM

1 3/4 12 UN 3A BEFORE PLATE SET THREAD PLUG GAGE 1.75 NO GO ONLY P.D. = 1.6902 - DW23958RD

PONAM

1 3/4 16 UN 3A BEFORE PLATE SET THREAD PLUG GAGE 1.75 GO NO GO = 1.7082 & 1.7050 - DW23956RD

PENNOYER DODGE

1 1/2 12 UNJF 3A BEFORE PLATE SET THREAD PLUG GAGE 1.5 GO ONLY P.D. = 1.4435 - DW23959RD

BATH

1.177 32 NS 3 SET THREAD PLUG GAGE 1.1770 GO NO GO P.D.'S = 1.1567 & 1.1529 - DW23977RD

BURDICK

1.025 32 LEFT HAND SET THREAD PLUG GAGE GO NO GO P.D.'S = 1.0047 & 1.0009 L.H. - DW23978RD
