ATLAS

ATLAS

3/8 27 NS THREAD RING GAGES .375 .3750 GO NO GO P.D.'S = .3509 & .3476 CHECK - DW24701RD

ATLAS

5/16 18 NS SPECIAL SET THREAD PLUG GAGE .3125 GO NO GO PDS= .2807 & .2797 CHECK - DW38242SLW

ATLAS

5/16 32 UNEF 2A SET THREAD PLUG GAGE .3125 GO NO GO P.D.'S = .2912 & .2880 CHECK - DW23867RD

ATLAS

5/16 40 NS LEFT HAND SET THREAD PLUG GAGE .3125 GO NO GO P.D.'S = .2963 & .2933 - DW22822RD

ATLAS

5/8 18 UNF 2A SET THREAD PLUG GAGE .625 GO NO GO P.D'S = .5889 & .5828 SETTING

ATLAS

5/8 18 UNF 2B SPECIAL THREAD PLUG GAGE .625 .6250 GO ONLY P.D. = .5879 2B OR 3B - DW26249RD

ATLAS

5/8 18 UNF 2B SPECIAL THREAD PLUG GAGE .625 GO NO GO PD'S = .5919 & .5980 CHECK - DW23054FKB

ATLAS

5/8 24 UNEF 2A SET THREAD PLUG GAGE .625 .6250 GO NO GO P.D.'S = .5967 & .5927 - 58242ASP1

ATLAS

55/64 14 NS 2 THREAD PLUG GAGE .859375 GO NO GO P.D.'S = .8130 & .8179 TOOLING

ATLAS

7/16 14 UNC 2A THREAD RING GAGES .4375 GO NO GO P.D.'S = .3897 & .3850 CHECK - CS6922BU

ATLAS

7/16 20 UNF 2A SPECIAL SET THREAD PLUG GAGE .4375 GO NO GO PD'S = .4021 & .3995 - DW33895CT4

ATLAS

7/16 20 UNF 3A LEFT HAND THREAD RING GAGES .4375 GO NO GO P.D.'S = .4050 & .4019 - DW3731BU
