LINCOLN GAGE

LINCOLN GAGE

.196 & .201 CL Z PIN PLUG GAGE GO NO GO .2031 -.0021 13/64 5 mm .1960 .2010 Z - DW11349BU

LINCOLN GAGE

.2200 & .2260 CLASS X PIN PLUG GAGE GO NO GO .2188 +.0012 OVERSIZE 7/32 5.740 mm

LINCOLN GAGE

.2490 & .2517 PIN PLUG GAGE GO NO GO .2500 -.0010 UNDERSIZE 1/4 6.325 mm .249 - DW10725BU

LINCOLN GAGE

.277 40 NS 2 SET THREAD PLUG GAGE .2770 GO NO GO P.D.'S = .2607 & .2575 CHECK - DW26338RD

LINCOLN GAGE

.365 48 NS 2B LEFT HAND THREAD PLUG GAGE GO NO GO P.D.'S = .3515 & .3547 UNS-2B - DW24341RD

LINCOLN GAGE

.365 48 NS 2B THREAD PLUG GAGE .3650 GO NO GO P.D.'S = .3515 & .3547 UNS-2B - DW24423RD

LINCOLN GAGE

.391 32 NS 2B N00 LOCKNUT THREAD PLUG GAGE GO NO GO PD'S = .3707 & .3733 CHECK - DW24224RD

LINCOLN GAGE

.4540 & .4630 CL XX PIN PLUG GAGE GO NO GO .4688 -.0148 15/32 11.760 .454 .463

LINCOLN GAGE

.586 32 NS N02 LOCKNUT SET THREAD PLUG GAGE .5860 GO ONLY P.D. = .5657 CHECK - DW26523LVR

LINCOLN GAGE

.6250 & .6255 CLASS XX PIN PLUG GAGE GO NO GO ONSIZE 5/8 16 mm .625 INSPECTION - DW11280BU

LINCOLN GAGE

.675 & .677 CL Z PIN PLUG GAGE GO NO GO .6719 +.0031 43/64 17 mm .6750 .6770 - DW11284BU

LINCOLN GAGE

.7495 & .7500 CL XX PIN PLUG GAGE GO NO GO .7500 -.0005 UNDERSIZE 3/4 19.037 mm
