ATLAS

ATLAS

M10 X 1 6g PREPLATE SET THREAD PLUG GAGE 10 1.0 GO NO GO P.D.'S = 9.260 & 9.149 - DW33888CT4

ATLAS

M10 X 1.5 6g METRIC SET THREAD PLUG GAGE 10 GO NO GO P.D.'S = .3540 & .3489 - DW42488BT6

ATLAS

M10 X 1.5 6g METRIC SET THREAD PLUG GAGE 10 NO GO ONLY P.D. = .3489 (8.862 mm) - DW42490BT6

ATLAS

M12 X 1 6g METRIC SET THREAD PLUG GAGE 12 1.0 GO NO GO P.D.'S = 11.324 & 11.206 - DW18485RD

ATLAS

M12 X 1 6g PREPLATE SET THREAD PLUG GAGE 12 1.0 GO NO GO PD'S = 11.263 & 11.145 - DW32897CT4

ATLAS

M12 X 1.5 6h METRIC SET THREAD PLUG GAGE 12 GO ONLY P.D. = 11.026 6g SPECIAL - DW33975CT4

ATLAS

M12 X 1.5 SPECIAL SET THREAD PLUG GAGE 12 GO ONLY P.D. = 10.953 INSPECTION CHECK - DW33899CT4

ATLAS

M12 X 1.75 6g METRIC SET THREAD PLUG GAGE 12 GO NO GO P.D.'S = 10.829 & 10.679 - DW42492BT6

ATLAS

M14 X 1.5 6g METRIC SPECIAL SET THREAD PLUG GAGE 14 GO ONLY P.D. = 12.966 CHECK - DW32891CT4

ATLAS

M14 X 1.5 6g METRIC THREAD RING GAGE 14 NO GO ONLY P.D. = 12.854 INSPECTION - NG0985BU

ATLAS

M16 X 1.5 6g METRIC BEFORE PLATE THREAD RING GAGE 16 GO ONLY P.D. = .5861 CHECK - DW41170BB6

ATLAS

M16 X 1.5 6g SET METRIC THREAD PLUG GAGE 16.0 GO NO GO P.D.'S = 15.024 & 14.854
