LC

LC

1" 8 ACME 2G LEFT HAND THREAD RING GAGE 1.0 1.00 NO GO ONLY P.D. = .9129 L.H. - DW21503CD2

LC

1.573 16 UNS 3A THREAD RING GAGE NO GO ONLY P.D. = 1.5263 NS-3A INSPECTION CHECK - DW6365RD

LC

1.629 CL Z MASTER PLAIN BORE RING GAGE 1.6250 +.0040 1 5/8 41.377 mm 1.6290 - DW15246RD

LC

1/2 32 NC 3 THREAD PLUG GAGE .5 .50 .500 GO NO GO P.D.'S = .4797 & .4823 UNC-3 - DW26331RD

LC

1/2 32 NC 3 THREAD RING GAGES .5 .50 .500 GO NO GO P.D.'S = .4797 & .4771 UNC-3 - DW14202RD

LC

1/4 18 NPSF PIPE THREAD PLUG GAGE .25 .250 GO NO GO P.D.'S = .4852 & .4904 2B - DW26673BN3

LC

11/16 18 UNF 3A THREAD RING GAGES .6875 GO NO GO P.D.'S = .6514 & .6479 CHECK - DW24218RD

LC

12 48 UNS 3A THREAD RING GAGES #12 .216 GO NO GO P.D.'S = .2025 & .2005 NS-3A

LC

15/16 12 UN 2A LEFT HAND THREAD RING GAGE .9375 NO GO ONLY P.D. = .8760 L.H.

LC

15/16 16 UN 2A PREPLATE SET THREAD PLUG GAGE .9375 GO ONLY P.D. = .8944 CHECK - DW27707RD

LC

2 11/16 32 UNS 2A THREAD RING GAGE 2.6875 GO ONLY P.D. = 2.6659 NS-2A CHECK - DW6329RD

LC

2 3/4 16 UN 2B THREAD PLUG GAGE 2.75 2.750 2.7500 NO GO ONLY P.D. = 2.7166 CHECK - DW28268LVR
