PMC INDUSTRIES

PMC INDUSTRIES

1" 14 UNS 2A HILO SET THREAD PLUG GAGE 1.0 GO ONLY P.D. = .9519 1.0 HI-LO

PMC INDUSTRIES

1" 16 UN 2A HILO SET THREAD PLUG GAGE 1.0 1.00 GO NO GO P.D.'S = .9579 & .9529 - DW21383AA3

PMC INDUSTRIES

1" 16 UN 2A HILO SET THREAD PLUG GAGE 1.0 GO ONLY P.D. = .9579 1.00 1.000 1-16

PMC INDUSTRIES

1.000 12 UNJF 3A BEFORE PLATE SET THREAD PLUG GAGE 1.0 1" NO GO ONLY PD = .9403

PMC INDUSTRIES

1.030 6 DARDELET THREAD RING GAGES 1.3 GO NO GO = .9810 & .9710 .060 TOOTH WIDTH - DW23212AM3

PMC INDUSTRIES

1.600 20 UNS 2A LEFT HAND THREAD RING GAGE 1.6 1.60 GO ONLY P.D. = 1.5661 L.H. - DW28059RD

PMC INDUSTRIES

1.600 20 UNS 2A LEFT HAND THREAD RING GAGE 1.6 GO ONLY P.D. = 1.5661 L.H. TOOL - DW4508RD

PMC INDUSTRIES

1.600 20 UNS 2A LEFT HAND THREAD RING GAGES 1.6 GO NO GO PDS= 1.5661 1.5613 LH

PMC INDUSTRIES

1.600 20 UNS 2A LEFT HAND THREAD RING GAGES 1.60 GO NO GO PDS= 1.5661 1.5613 LH

PMC INDUSTRIES

1.704 CLASS X SMOOTH BORE RING GAGE 1.6875 + .0165 OVERSIZE 1 11/16 INSPECTION

PMC INDUSTRIES

1.8504 CLASS Z SMOOTH PLAIN BORE RING GAGE 1.875 - .0246 UNDERSIZE 1 7/8 PMC
