PRATT & WHITNEY

PRATT & WHITNEY

3/8 16 NC STUD THREAD PLUG GAGE .375 GO NO GO P.D.'S = .3340 & .3344 QUALITY

PRATT & WHITNEY

3/8 16 NC UNDER BASIC STUD THREAD PLUG GAGE .375 GO NO GO P.D.'S = .3340 & .3344

PRATT & WHITNEY

3/8 18 ANPT L1 3 STEP PIPE THREAD PLUG GAGE .375 A.N.P.T. QUALITY INSPECTION

PRATT & WHITNEY

3/8 36 NS 3 THREAD RING GAGES .375 GO NO GO P.D.'S = .3570 & .3546 INSPECTION

PRATT & WHITNEY

7/16 14 NC SPECIAL CARBIDE THREAD RING GAGES .4375 GO NO GO PD'S = .3967 & .3947

PRATT & WHITNEY

7/16 20 NF LEFT HAND THREAD PLUG GAGE .4375 GO NO GO P.D.'S = .4024 & .4050

PRATT & WHITNEY

7/16 24 CLASS 3 THREAD PLUG GAGE .4375 NO GO ONLY P.D. = .4130

PRATT & WHITNEY

1/2 20 UNF THREAD RING GAGE .5 .50 .500 .5000 GO ONLY P.D. = .4675 3A CHECK - BM0777

PRATT & WHITNEY

9/16 18 3B STI HELICOIL THREAD PLUG GAGE .5625 GO NO GO P.D.'S = .5986 & .6020

PRATT & WHITNEY

9/16 18 NF SET THREAD PLUG GAGE .5625 GO NO GO P.D.'S = .5254 & .5224 INSPECTION

PRATT & WHITNEY

5/8 11 NC OVERBASIC SET THREAD PLUG GAGE .625 GO ONLY P.D. = .5725 5/8-11 TOOL

PRATT & WHITNEY

5/8 11 NC OVERBASIC THREAD PLUG GAGE .625 GO NO GO P.D.'S = .5710 & .5769 TOOLS
