MERCURY

MERCURY

5/16 24 UNS 2A -.001 UNDERSIZE THREAD RING GAGE .3125 GO ONLY P.D. = .2833 NS-2A

MERCURY

5/32 32 NS 2 THREAD RING GAGES .15625 .1562 GO NO GO P.D.'S = .1359 & .1332 - DW13247AG1

MERCURY

5/8 18 NF 3B THREAD PLUG GAGE .625 NO GO ONLY P.D. = .5934 5/8-18 NF-3B QUALITY

MERCURY

5/8 18 UNC 2A PREPLATE THREAD RING GAGES .625 GO NO GO P.D.'S = .5859 & .5822 - DW32864CT4

MERCURY

5/8 24 UNEF 2A THREAD RING GAGE .625 NO GO ONLY P.D. = .5927 NEF-2A INSPECTION - DW7445BU

MERCURY

6 32 UNC 2A THREAD RING GAGE #6 .138 .1380 GO ONLY P.D. = .1426 INSPECTION CHECK - DW13733LVR

MERCURY

6 32 UNC 2B THREAD PLUG GAGE #6 .138 NO GO ONLY P.D. = .1214 QUALITY #6-32 TOOL

MERCURY

6 48 UNF 3A LEFT HAND THREAD RING GAGES #6 .138 GO NO GO P.D.'S = .1245 & .1226 - DW27903LVR

MERCURY

7 1/2 8 UN 2A THREAD RING GAGE 7.5 7.50 7.500 7.5000 GO ONLY P.D. = 7.4163 CHECK - DW27133AJ4

MERCURY

7 1/2 8 UN THREAD PLUG GAGE 7.5 7.50 7.500 7.5000 GO ONLY P.D. = 7.4188 2B OR 3B - DW27013AJ4

MERCURY

7/16 14 NS THREAD RING GAGE .4375 GO ONLY P.D. = .3917 QUALITY INSPECTION TOOL

MERCURY

7/16 14 UNJC 3A THREAD RING GAGES .4375 GO NO GO P.D.'S = .3911 & .3876 CHECK - DW35224LVR
