Ring Gages

TAFT PEIRCE

3 1/2 10 NS 3 THREAD RING GAGE 3.5 3.50 3.500 3.5000 GO ONLY P.D. = 3.435 - DW13372RD

G.A. CO.

9/16 20 NS 2 THREAD RING GAGES .5625 GO NO GO P.D.'S = .5300 & .5259 INSPECTION - DW13360RD

GTD

2 3/8 16 NS 3 THREAD RING GAGES 2.375 2.3750 GO NO GO P.D.'S = 2.3344 & 2.3277 - DW13375RD

PRATT & WHITNEY

15/16 20 NEF 2 THREAD RING GAGES .9375 GO NO GO P.D.'S = .9050 & .9003 UNEF-2 - DW13367RD

2 7/16 16 NS 3 THREAD RING GAGES 2.4375 GO NO GO P.D.'S = 2.3969 & 2.3924 CHECK - DW13370RD

MERCURY

3/8 32 NEF 3 THREAD RING GAGES .375 .3750 GO NO GO P.D.'S = .3547 & .3523 UNEF-3 - DW13363RD

2 5/8 16 N 3 THREAD RING GAGES 2.625 2.6250 GO NO GO P.D.'S = 2.5844 & 2.5799 - DW13377RD

2 5/16 16 N 3 THREAD RING GAGES 2.3125 GO NO GO P.D.'S = 2.2719 & 2.2675 CHECK - DW13371RD

KOBE

3.922 11 NS 3 THREAD RING GAGES 3.9220 GO NO GO P.D.'S = 3.8630 & 3.8564 CHECK - DW13378RD

3/8 32 NS 2 SOLID THREAD RING GAGES .375 .3750 GO NO GO P.D.'S = .3547 & .3514 - DW13359RD

2 1/2 24 NS 3 THREAD RING GAGES 2.5 2.50 2.500 GO NO GO P.D.'S = 2.4729 & 2.4664 - DW13374RD

GTD

2 7/16 16 N 3 THREAD RING GAGES 2.4375 GO NO GO P.D.'S = 2.3969 & 2.3924 CHECK - DW13376RD
