Ring Gages

HEMCO

4 48 NF 3 THREAD RING GAGES #4 .112 .1120 GO NO GO P.D.'S = .0985 & .0969 UNF-3 - DW13354RD

YOU ARE PURCHASING THE PICTURED RIGHT HAND THREAD RING GAGES.SOLD BY M & J TOOLING LLCDAYTON, OHIO<

ATLAS

1" 16 N BUTT 3 BUTTRESS THREAD RING GAGE 1.0 1.00 1.000 NO GO ONLY P.D. = .9541 - DW13347RD

YOU ARE PURCHASING THE PICTURED BUTTRESS THREAD RING GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

1/2 48 NS 3 SOLID THREAD RING GAGES .5 .50 .500 GO NO GO P.D.'S = .4865 & .4839 - DW13352RD

YOU ARE PURCHASING THE PICTURED SOLID THREAD RING GAGES.SOLD BY M & J TOOLING LLCDAYTON, OHIO<

PM CO.

3/8 16 NC THREAD RING GAGE .375 .3750 GO ONLY P.D. = .3344 UNC 3A INSPECTION - DW13353RD

YOU ARE PURCHASING THE PICTURED RIGHT HAND THREAD RING GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

59/64 48 NS 3 SOLID THREAD RING GAGE .921875 GO ONLY P.D. = .9084 INSPECTION - DW13340RD

YOU ARE PURCHASING THE PICTURED SOLID THREAD RING GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

HANSON WHITNEY

7/16 14 NC 4 THREAD RING GAGES .4375 GO NO GO P.D.'S = .3915 & .3897 UNC-4 CHECK - DW13350RD

YOU ARE PURCHASING THE PICTURED THREAD RING GAGES.SOLD BY M & J TOOLING LLCDAYTON, OHIO

HANSON WHITNEY

5/8 20 NS 3 THREAD RING GAGES .625 .6250 GO NO GO P.D.'S = .5925 & .5895 CHECK - DW13342RD

YOU ARE PURCHASING THE PICTURED THREAD RING GAGES.SOLD BY M & J TOOLING LLCDAYTON, OHIO

11/16 18 NS 3 THREAD RING GAGES .6875 GO NO GO P.D.'S = .6514 & .6484 CHECK - DW13321RD

YOU ARE PURCHASING THE PICTURED THREAD RING GAGES.SOLD BY M & J TOOLING LLCDAYTON, OHIO

HANSON WHITNEY

2 3/8 18 NS 3 THREAD RING GAGES 2.375 2.3750 GO NO GO P.D.'S = 2.3389 & 2.3323 - DW13338RD

YOU ARE PURCHASING THE PICTURED THREAD RING GAGES.SOLD BY M & J TOOLING LLCDAYTON, OHIO

GTD

5/8 36 NS 3 THREAD RING GAGES .625 .6250 GO NO GO P.D.'S = .607 & .604 CHECK - DW13326RD

YOU ARE PURCHASING THE PICTURED THREAD RING GAGES.SOLD BY M & J TOOLING LLCDAYTON, OHIO

SHEFFIELD

.4910 24 NS 3A THREAD RING GAGE .491 GO ONLY P.D. = .4639 .4910"-24 UNS - DW13319RD

YOU ARE PURCHASING THE PICTURED THREAD RING GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

GTD

11/16 18 NS 3 THREAD RING GAGES .6875 GO NO GO P.D.'S = .6514 & .6484 CHECK - DW13322RD

YOU ARE PURCHASING THE PICTURED THREAD RING GAGES.SOLD BY M & J TOOLING LLCDAYTON, OHIO
