Ring Gages

PRATT & WHITNEY

5 44 NF 3 THREAD RING GAGES #5 .125 GO NO GO P.D.'S = .1102 & .1086 UNF-3 .1250 - DW10479RD

YOU ARE PURCHASING THE PICTURED THREAD RING GAGES.SOLD BY M & J TOOLING LLCDAYTON, OHIO

HANSON WHITNEY

.5624 24 NS 1 THREAD RING GAGE NO GO ONLY P.D. = .5284 9/16"-24 INSPECTION CHECK - DW10476RD

YOU ARE PURCHASING THE PICTURED THREAD RING GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

METRO

.4900 32 NS 2 THREAD RING GAGE .49 .490 GO ONLY P.D. = .4697 UNS-3A INSPECTION - DW10457RD

YOU ARE PURCHASING THE PICTURED THREAD RING GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

GTD

.760 12 NS 3 DOUBLE LEAD THREAD RING GAGES .76 GO NO GO P.D.'S = .7084 & .7044 - DW10454RD

YOU ARE PURCHASING THE PICTURED DOUBLE LEAD THREAD RING GAGES.SOLD BY M & J TOOLING LLCDAYTON, OHIO

HANSON WHITNEY

.098 100 THREAD RING GAGES GO NO GO P.D.'S = .0915 & .0900 .0980 INSPECTION - DW10453RD

YOU ARE PURCHASING THE PICTURED THREAD RING GAGES.SOLD BY M & J TOOLING LLCDAYTON, OHIO

1.561 20 NS 1 LEFT HAND THREAD RING GAGES GO NO GO P.D.'S = 1.5270 & 1.5196 L.H. - DW10464RD

YOU ARE PURCHASING THE PICTURED LEFT HAND THREAD RING GAGES.SOLD BY M & J TOOLING LLCDAYTON, OHIO

METRO

.4700 32 NS 3 THREAD RING GAGE .47 .470 GO ONLY P.D. = .4497 UNS-3A - DW10456RD

YOU ARE PURCHASING THE PICTURED THREAD RING GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

GTD

.760 13 NS 3 DOUBLE LEAD THREAD RING GAGES .76 GO NO GO P.D.'S = .7101 & .7061 - DW10447RD

YOU ARE PURCHASING THE PICTURED DOUBLE LEAD THREAD RING GAGES.SOLD BY M & J TOOLING LLCDAYTON, OHIO

GTD

.9062 24 NS 2 THREAD RING GAGE GO ONLY P.D. = .8791 INSPECTION CHECK 29/32 3A - DW10431RD

YOU ARE PURCHASING THE PICTURED THREAD RING GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

HANSON WHITNEY

5/8 18 NF 3 THREAD RING GAGE .625 NO GO ONLY P.D. = .5859 UNF-3 .6250 CHECK - DW10445RD

YOU ARE PURCHASING THE PICTURED THREAD RING GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

17/32 28 NS 2 THREAD RING GAGES .53125 .5312 GO NO GO P.D.'S = .5081 & .5040 - DW10441RD

YOU ARE PURCHASING THE PICTURED THREAD RING GAGES.SOLD BY M & J TOOLING LLCDAYTON, OHIO

GTD

23/32 48 NS THREAD RING GAGE .71875 GO ONLY P.D. = .7052 23/32"-48 3A .7187 - DW10443RD

YOU ARE PURCHASING THE PICTURED THREAD RING GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO
