Working Plug Gages for Checking Threaded Holes

2.738 11 1/2 NS 3 THREAD PLUG GAGE 2.7380 GO NO GO P.D.'S = 2.6815 & 2.6884 - DW13364RD

BATH

1 7/16 16 NS 1 THREAD PLUG GAGE 1.4375 NO GO ONLY P.D. = 1.4048 INSPECTION CHECK - DW13368RD

PTG

1.582 32 NS 3 THREAD PLUG GAGE 1.5820 GO NO GO P.D.'S = 1.5617 & 1.5659 CHECK - DW13366RD

BUDGET 2.738 11 1/2 NS 3 THREAD PLUG GAGE 2.7380 GO P.D. = 2.6815 GO AND NO GO - DW13373RD

GTD

11/16 16 NS 3 THREAD PLUG GAGE .6875 GO NO GO P.D.'S = .6469 & .6501 INSPECTION - DW13346RD

7/16 20 NF 3 LEFT HAND THREAD PLUG GAGE .4375 GO NO GO P.D.'S = .4050 & .4076 - DW13348RD

1.356 32 NS SPECIAL THREAD PLUG GAGE 1.3560 GO NO GO P.D.'S = 1.3357 & 1.3422 - DW13332RD

WOODWORTH

1 1/2 32 NS 3 THREAD PLUG GAGE 1.5 1.50 1.500 GO NO GO P.D.'S = 1.4797 & 1.4885 - DW13337RD

1 9/16 32 NS 3 THREAD PLUG GAGE 1.5625 GO NO GO P.D.'S = 1.5422 & 1.5476 CHECK - DW13335RD

5/8 11 NC 3 THREAD PLUG GAGE .625 .6250 GO NO GO P.D.'S = .5660 & .5702 UNC-3 - DW13328RD

2 7/8 6 STUB ACME 2G THREAD PLUG GAGE 2.875 2.8750 NO GO ONLY P.D. = 2.8474 - DW13310BHTX

DURA

2" 4 1/2 NC THREAD PLUG GAGE 2.0 2.00 2.000 GO ONLY P.D. = 1.8557 UNC 2B OR 3B - DW13301AJ1
