Working Plug Gages for Checking Threaded Holes

HEMCO

4 7/8 6 STUB ACME 2G THREAD PLUG GAGE 4.875 GO NO GO P.D.'S = 4.8250 & 4.8505 - DW9875BHTX

HEMCO

5 1/8 8 STUB ACME 2G THREAD PLUG GAGE 5.125 GO NO GO P.D.'S = 5.0875 & 5.1117 - DW9876BHTX

M135 X 4 ISO 6H METRIC THREAD PLUG GAGE GO NO GO P.D.'S = 132.402 & 132.737 - DW9854BHTX

GAGE ASSEMBLY CO.

7.94 12 UNS 2B THREAD PLUG GAGE GO NO GO P.D.'S = 7.8834 & 7.8920 7.940 7.9400 - DW9632BU

5.94 12 UNS 2B THREAD PLUG GAGE GO NO GO P.D.'S = 5.8834 & 5.8920 5.940 5.9400 - DW9360BU

VERMONT GAGE

7 3/16 12 UNS 2B VERMONT THREAD PLUG GAGE 7.1875 GO NO GO PD'S = 7.1334 & 7.1426 - DW9226HX

VTG

5 1/4 8 UN 2A VERMONT THREAD PLUG GAGE 5.25 GO NO GO P.D.'S = 5.1659 & 5.1561 - DW9211BU

HEMCO

5" 2 NA 3G STUB ACME THREAD PLUG GAGE 5.0 2.0 GO NO GO P.D.'S = 4.8500 & 4.8662 - DW8159BU

5 1/4 12 UNJ 3B SPECIAL THREAD PLUG GAGE 5.25 GO NO GO P.D.'S = 5.1979 & 5.2025 - DW7722BU

2" 16 UN 3B SOLID CARBIDE THREAD PLUG GAGE 2.0 GO NO GO P.D.'S = 1.9594 & 1.9646 - DW7232BU

HEMCO

6 1/4 5 SPEC. BUTTRESS SPECIAL BUTTRESS THREAD PLUG GAGE 6.25 5.0 GO NO GO = 6.1050 6.0850 - DW5409BU

SCHRILLO

5 1/4 10 NA SPL SPECIAL ACME THREAD PLUG GAGE 5.25 GO NO GO PDS= 5.2000 & 5.2060 - DW4993RD
