Working Plug Gages for Checking Threaded Holes

PENNOYER DODGE

M18 X 1.5 SPECIAL THREAD PLUG GAGE 18 GO NO GO P.D.'S = .6703 & .6753 INSPECTION - DW27028LVR

PONAM

15/16 20 UNEF 3B THREAD PLUG GAGE .9375 GO NO GO P.D.'S = .9050 & .9094 CHECK - DW27032LVR

MERCURY

7 1/2 8 UN THREAD PLUG GAGE 7.5 7.50 7.500 7.5000 GO ONLY P.D. = 7.4188 2B OR 3B - DW27013AJ4

VERMONT GAGE

M4 X .7 6G METRIC VERMONT THREAD PLUG GAGE 4 0.7 NO GO ONLY P.D. = 3.685 CHECK - DW27000LVR

VERMONT GAGE

M8 X 1.25 6H METRIC VERMONT THREAD PLUG GAGE 8 NO GO ONLY P.D. = 7.348 CHECK - DW26999LVR

VERMONT GAGE

8 32 UNC 2B SPECIAL VERMONT THREAD PLUG GAGE #8 .164 NO GO ONLY P.D. = .1457 SPL - DW26998LVR

VERMONT GAGE

M6 X .75 6H METRIC SPECIAL VERMONT THREAD PLUG GAGE 6 0.75 GO ONLY P.D. = .2171 - DW27004LVR

THREADCHECK

6 32 UNC STI HELICOIL THREAD PLUG GAGE #6 .138 GO ONLY P.D. = .1583 2B OR 3B - DW27003LVR

VERMONT GAGE

6 32 UNC VERMONT THREAD PLUG GAGE #6 .138 .1380 GO ONLY P.D. = .1177 2B OR 3B - DW27002LVR

VERMONT GAGE

M6 X 1 6H METRIC VERMONT THREAD PLUG GAGE 6 1.0 NO GO ONLY P.D. = 5.500 CHECK - DW26995LVR

VERMONT GAGE

BUDGET 8 32 UNC VERMONT THREAD PLUG GAGE #8 .164 GO ONLY P.D. = .1437 2B OR 3B - DW27001LVR

3.5675 8 NS 3 THREAD PLUG GAGE GO ONLY P.D. = 3.4863 3.5675"-8 INSPECTION CHECK - DW26986AJ4
