Working Plug Gages for Checking Threaded Holes

BATH

7" 10 UNS 2B THREAD PLUG GAGE 7.0 GO NO GO P.D.'S = 6.9350 & 6.9448 UN NS N-2B

M47 X .5 6H METRIC THREAD PLUG GAGE 47.0 0.5 GO NO GO P.D.'S = 46.675 & 46.807

G.A. CO.

5 3/8 16 UN 3B THREAD PLUG GAGE 5.375 GO NO GO P.D.'S = 5.3344 & 5.3403 N-3B

LINCOLN GAGE

0.965 80 UNS 2B THREAD PLUG GAGE .965 .9650 GO NO GO P.D.'S = .9569 & .9602 N-2B

5 15/16 12 UNS 3B THREAD PLUG GAGE 5.9375 5.937 GO NO GO P.D.'S= 5.8834 & 5.8874

TITAN GAGE

6 5/16 12 UNS 3B THREAD PLUG GAGE 6.3125 6.312 GO NO GO P.D.'S = 6.2579 & 6.2646

TITAN GAGE

7 1/4 12 UNS 3B THREAD PLUG GAGE 7.25 GO NO GO P.D.'S = 7.1960 & 7.2000 7.250-12

GAGE ASSEMBLY CO.

CERTIFIED 4.235 4 ACME 2G THREAD PLUG GAGES 4.0 GO NO GO P.D.'S = 4.110 & 4.1373

3 3/8 12 UN 2A THREAD PLUG GAGE 3.375 GO NO GO P.D.'S = 3.3190 & 3.3126 TOOL

GAGE ASSEMBLY CO.

M162 X 2 6H METRIC THREAD PLUG GAGE 162.0 2.0 GO NO GO P.D.'S = 160.701 & 160.95

5 1/4 12 UNS 3B THREAD PLUG GAGE 5.25 GO NO GO P.D.'S = 5.1959 & 5.2009 NS-2B

PENNOYER-DODGE CO.

7.076 16 UNS 3B THREAD PLUG GAGES 7.0760 GO NO GO P.D.'S = 7.0354 & 7.0417 NS-3B
