Working Plug Gages for Checking Threaded Holes

HANSON WHITNEY

CERTIFIED 7/8 14 UNF 3B THREAD PLUG GAGE .875 GO NO GO P.D.'S = .8286 & .8339 - DW26507TLC

REGAL BELOIT

CERTIFIED 3/4 10 UNC 3B THREAD PLUG GAGE .75 GO NO GO P.D.'S = .6850 & .6907 - DW26479TLC

SWANSON

CERTIFIED 7/8 9 UNC 2B THREAD PLUG GAGE .875 GO NO GO P.D.'S = .8028 & .8110 - DW26469TLC

CERTIFIED 3/4 20 UNEF 2B THREAD PLUG GAGE .75 GO NO GO P.D.'S = .7175 & .7232 - DW26472TLC

ACCU-GAGE

CERTIFIED 13/16 20 UNEF 2B THREAD PLUG GAGE .8125 GO NO GO PD'S = .7800 & .7857 - DW26471TLC

HANSON WHITNEY

CERTIFIED 7/8 9 UNC 3B THREAD PLUG GAGE .875 GO NO GO P.D.'S = .8028 & .8089 - DW26474TLC

PENNOYER DODGE

CERTIFIED 5/8 18 UNF 3B THREAD PLUG GAGE .625 GO NO GO P.D.'S = .5889 & .5934 - DW26475TLC

TITAN GAGE

CERTIFIED 3/4 10 UNC 2B THREAD PLUG GAGE .75 GO NO GO P.D.'S = .6850 & .6927 - DW26478TLC

REGAL BELOIT

CERTIFIED 5/8 24 UNEF 2B THREAD PLUG GAGE .625 GO NO GO P.D.'S = .5979 & .6031 - DW26477TLC

G.A. CO.

CERTIFIED 13/16 20 UNEF 3B THREAD PLUG GAGE .8125 GO NO GO PD'S = .7800 & .7843 - DW26470TLC

TITAN GAGE

CERTIFIED 3/4 16 UNF 2B THREAD PLUG GAGE .75 GO NO GO P.D.'S = .7094 & .7159 - DW26480TLC

EFCO

CERTIFIED 5/8 18 UNJF 3B THREAD PLUG GAGE .625 GO NO GO P.D.'S = .5889 & .5934 - DW26476TLC
