Working Plug Gages for Checking Threaded Holes

WESTPORT

9/16 8 NS 2B MODIFIED 60 DEGREES THREAD PLUG GAGE .5625 GO NO GO = .5072 .5128 - DW26376RD

BENDIX BESLY

9/16 8 STUB ACME THREAD PLUG GAGE .5625 GO NO GO P.D.'S = .5250 & .5404 2G - DW26370RD

BENDIX BESLY

9/16 8 NA MODIFIED ACME THREAD PLUG GAGE .5625 GO NO GO PD'S = .5000 & .5155 2G - DW26373RD

BENDIX

9/16 8 STUB ACME LEFT HAND THREAD PLUG GAGE .5625 GO NO GO PDS= .5250 & .5404 2G - DW26363RD

HEMCO

BUDGET M22 X 1.5 THREAD PLUG GAGE 22 GO ONLY METRIC INSPECTION CHECK - DW26357RD

PIPE MACHINERY CO.

1 3/16 20 NS 1 THREAD PLUG GAGE 1.1875 GO ONLY P.D. = 1.1550 UNS 2B OR 3B - DW26356RD

REGAL

2.103 14 NS THREAD PLUG GAGE 2.1030 GO ONLY P.D. = 2.0566 2.103"-14 UNS 2B 3B - DW26353RD

SPIRALOCK

5/16 18 SPL SPIRALOCK THREAD PLUG GAGE .3125 GO ONLY P.D. = 49580 INSPECTION - DW26354RD

G. WHALLEY

10 24 UNC 3B THREAD PLUG GAGE #10 .190 .1900 NO GO ONLY P.D. = .1661 INSPECTION - DW26350RD

DETROIT

3/8 24 NF 2B LEFT HAND THREAD PLUG GAGE .375 NO GO ONLY P.D. = .3528 UNF-2B L.H. - DW26342RD

LC

1/2 32 NC 3 THREAD PLUG GAGE .5 .50 .500 GO NO GO P.D.'S = .4797 & .4823 UNC-3 - DW26331RD

DOALL

1 1/4 16 NS 3 THREAD PLUG GAGE 1.25 1.250 1.2500 GO ONLY P.D. = 1.2094 UNS 2B 3B - DW26328RD
