Working Plug Gages for Checking Threaded Holes

4 7/16 12 UNS 3B THREAD PLUG GAGE 4.4375 NO GO ONLY P.D. = 4.3898 INSPECTION - DW32213CF4

4 3/16 12 UNS 2B THREAD PLUG GAGE 4.1875 GO ONLY P.D. = 4.1334 2B OR 3B CHECK - DW32212CF4

VERMONT GAGE

3 11/16 12 UNS 3B VERMONT THREAD PLUG GAGE 3.6875 GO ONLY P.D. = 3.6334 3B OR 2B - DW32211CF4

VERMONT GAGE

4 11/16 12 UNS 3B VERMONT THREAD PLUG GAGE 4.6875 NO GO ONLY P.D. = 4.6399 CHECK - DW32209CF4

M14 X 1 4H5H METRIC THREAD PLUG GAGE 14 1.0 GO NO GO P.D.'S = 13.350 & 13.450 - DW32207CM4

M12 X 1 4H5H METRIC THREAD PLUG GAGE 12 1.0 GO NO GO P.D.'S = 11.350 & 11.450 - DW32206CM4

LEITECH

BUDGET M6 X 1 6H DEPTH THREAD PLUG GAGE 6 1.0 GO NO GO = 5.350 & 5.500 LEITECH - DW32205CM4

DURA

M21 X 2.5 6H LEFT HAND THREAD PLUG GAGE 21 GO NO GO P.D.'S = .7629 & .7717 CHECK - DW32204CM4

LEITECH

M12 X 1.75 6H DEPTH THREAD PLUG GAGE 12 GO NO GO PD'S = 10.863 & 11.063 LEITECH - DW32203CM4

LEITECH

M8 X 1.25 6H DEPTH THREAD PLUG GAGE 8 GO NO GO P.D.'S = 7.188 & 7.348 LEITECH - DW32202CM4

GTD

NEW M10 X 1.5 6H METRIC THREAD PLUG GAGE 10 GO ONLY P.D. = 9.026 INSPECTION - DW32201CM4

GF GAGE

CERTIFIED 1/2 13 UNC 2B STI HELICOIL THREAD PLUG GAGE .5 GO NO GO = .5499 .5554 - DW32195CM4
