Working Plug Gages for Checking Threaded Holes

GTD

5/8 11 NC 3 THREAD PLUG GAGE .625 .6250 NO GO ONLY P.D. = .5702 UNC-3 CHECK - DW26269RD

YOU ARE PURCHASING THE PICTURED RIGHT HAND THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

THREADS INC.

7/16 14 UNC 3B STI HELICOIL THREAD PLUG GAGE .4375 GO NO GO PD'S = .4839 & .4875 - DW26276RD

YOU ARE PURCHASING THE PICTURED STI HELICOIL THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

EXACTO

1/2 14 NA 3C ACME THREAD PLUG GAGE .5 .50 GO NO GO P.D.'S = .4643 & .4700 UNA-3C - DW26266RD

YOU ARE PURCHASING THE PICTURED RIGHT HAND THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

WEDIN

.945 64 NS 3B THREAD PLUG GAGE .9450 GO ONLY P.D. = .9349 UNS-3B OR 2B CHECK - DW26263RD

YOU ARE PURCHASING THE PICTURED RIGHT HAND THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

EXACTO

1/2 14 NA 3C LEFT HAND ACME THREAD PLUG GAGE .5 GO NO GO P.D.'S = .4643 & .4700 - DW26264RD

YOU ARE PURCHASING THE PICTURED LEFT HAND THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

ACCU-GAGE

9/32 24 UNS 2B THREAD PLUG GAGE .28125 NO GO ONLY P.D. = .2591 INSPECTION CHECK - DW26251RD

YOU ARE PURCHASING THE PICTURED RIGHT HAND THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

ACCU-GAGE

M8 X 1.25 6H METRIC THREAD PLUG GAGE 8 GO ONLY P.D. = 7.188 INSPECTION CHECK - DW26253RD

YOU ARE PURCHASING THE PICTURED RIGHT HAND THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

4 7/8 8 MODIFIED WHITWORTH THREAD PLUG GAGE 4.875 4.8750 GO ONLY P.D. = 4.799 - DW26256RD

YOU ARE PURCHASING THE PICTURED RIGHT HAND MODIFIED WHITWORTH THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

ACCU-GAGE

M3.5 X .6 6H METRIC THREAD PLUG GAGE 3.5 0.6 GO ONLY P.D. = 3.110 INSPECTION - DW26254RD

YOU ARE PURCHASING THE PICTURED RIGHT HAND THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

OSBORN

M27.790 X .5 4H5H PREPLATE THREAD PLUG GAGE 27.790 0.5 GO NO GO = 27.475 27.551 - DW26245RD

YOU ARE PURCHASING THE PICTURED RIGHT HAND PREPLATE THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

THREDCO

M4 X .7 6H METRIC THREAD PLUG GAGE 4 0.7 NO GO ONLY P.D. = 3.663 INSPECTION - DW26250RD

YOU ARE PURCHASING THE PICTURED RIGHT HAND THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

1.112 40 UNS 2B THREAD PLUG GAGE 1.1120 GO NO GO P.D.'S = 1.0958 & 1.1003 CHECK - DW26241RD

YOU ARE PURCHASING THE PICTURED RIGHT HAND THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO
