Working Plug Gages for Checking Threaded Holes

NEW 10 32 UNF 2B THREAD PLUG GAGE #10 .190 .1900 GO NO GO P.D.'S = .1697 & .1736 - DW30997MSAF

NEW M5.5 X .5 6H METRIC THREAD PLUG GAGE 5.5 0.5 GO NO GO P.D.'S = 5.175 & 5.275 - DW30996MSAF

NEW M10 X 1.25 6H METRIC THREAD PLUG GAGE 10 GO NO GO P.D.'S = 9.188 & 9.348 - DW30995MSAF

ALAMEDA

2 7/8 12 UNJ 3B THREAD PLUG GAGE 2.875 2.8750 GO NO GO P.D.'S = 2.8209 & 2.8271 - DW30992LVR

ALAMEDA

2 5/8 8 UN 2B THREAD PLUG GAGE 2.625 2.6250 GO NO GO P.D.'S = 2.5438 & 2.5545 - DW30991LVR

ALAMEDA

13/16 20 UNJEF 3B THREAD PLUG GAGE .8125 GO NO GO P.D.'S = .7800 & .7843 CHECK - DW30989BQ4

IDEAL

11/16 24 UNJEF 3B THREAD PLUG GAGE .6875 GO NO GO P.D.'S = .6604 & .6643 CHECK - DW30988BQ4

ALAMEDA

1 1/2 12 UNF 2B THREAD PLUG GAGE 1.5 1.50 GO NO GO P.D.'S = 1.4459 & 1.4542 - DW30987BQ4

IDEAL

7/8 32 UN 2B MODIFIED THREAD PLUG GAGE .875 GO NO GO P.D.'S = .8567 & .8614 - DW30986BQ4

PENNOYER DODGE

1 1/8 16 UNJ 3B THREAD PLUG GAGE 1.125 1.1250 GO NO GO P.D.'S = 1.0844 & 1.0893 - DW30985BQ4

PONAM

1 1/4 24 UNS 2B THREAD PLUG GAGE 1.25 1.250 GO NO GO P.D.'S = 1.2229 & 1.2285 - DW30984BQ4

IDEAL

1 1/16 28 UN 2B THREAD PLUG GAGE 1.0625 GO NO GO P.D.'S = 1.0393 & 1.0445 CHECK - DW30983BQ4
