Working Plug Gages for Checking Threaded Holes

IDEAL

5 1/2 8 UNJS BEFORE PLATE THREAD PLUG GAGE 5.5 NO GO ONLY P.D. = 5.4269 - DW12150RD

YOU ARE PURCHASING THE PICTURED BEFORE PLATE THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

5 1/2 8 UNS MOD BEFORE PLATE THREAD PLUG GAGE 5.5 GO ONLY P.D. = 5.4220 2B OR 3B - DW12149RD

YOU ARE PURCHASING THE PICTURED BEFORE PLATE THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

LOCKE

1/4 28 NF 2 THREAD PLUG GAGE .25 GO NO GO P.D.'S = .2270 & .2290 UNF-2 .250 - DW12132RD

YOU ARE PURCHASING THE PICTURED THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

METRO

7/16 14 NC 3 THREAD PLUG GAGE .4375 GO NO GO P.D.'S = .3911 & .3947 UNC-3 CHECK - DW12111RD

YOU ARE PURCHASING THE PICTURED THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

1 1/8 7 NC 2 THREAD PLUG GAGE 1.125 GO ONLY P.D. = 1.0372 UNC-2 2B OR 3B 1.1250 - DW12127RD

YOU ARE PURCHASING THE PICTURED THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

TAFT-PEIRCE

1/4 28 NF 3 THREAD PLUG GAGE .25 .250 GO NO GO P.D.'S = .2268 & .2290 UNF-3 - DW12117RD

YOU ARE PURCHASING THE PICTURED THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

ALAMEDA

9/16 18 UNF 2B THREAD PLUG GAGE .5625 GO NO GO P.D.'S = .5264 & .5323 CHECK - DW12201BURL

YOU ARE PURCHASING THE PICTURED THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

THREDCO

1 3/4 12 NS 3 THREAD PLUG GAGE 1.75 NO GO ONLY P.D. = 1.7005 1.750 1.7500 CHECK - DW12101RD

YOU ARE PURCHASING THE PICTURED THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

GTD

1/2 20 NF 2 THREAD PLUG GAGE .5 .50 .500 GO NO GO P.D.'S = .4675 & .4711 UNF-2 - DW12077RD

YOU ARE PURCHASING THE PICTURED RIGHT HAND THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

PRATT & WHITNEY

7/8 40 CL 3 THREAD PLUG GAGE .875 GO NO GO P.D.'S = .8588 & .8621 .8750 - DW12076RD

YOU ARE PURCHASING THE PICTURED THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

HEMCO

.296 34 UN THREAD PLUG GAGE GO NO GO P.D.'S = .2769 & .2799 .2960 INSPECTION - DW12065AC1

YOU ARE PURCHASING THE PICTURED THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO

G.A. CO.

.296 34 UNS THREAD PLUG GAGE GO NO GO P.D.'S = .2769 & .2799 .2960 INSPECTION - DW12066AC1

YOU ARE PURCHASING THE PICTURED THREAD PLUG GAGE.SOLD BY M & J TOOLING LLCDAYTON, OHIO
