Working Plug Gages for Checking Threaded Holes

PIPE MACHINERY

15/32 32 NS 2 THREAD PLUG GAGE .4687 GO NO GO P.D.'S = .4485 & .4521 INSPECTION - DW32090OB4

REGAL PREMIUM

M5.5 X .5 6H METRIC THREAD PLUG GAGE 5.5 0.5 GO NO GO P.D.'S = 5.175 & 5.275 - DW32089OB4

TRUTHREAD

1 1/16 12 UNJ 3B THREAD PLUG GAGE 1.0625 GO NO GO P.D.'S = 1.0084 & 1.0139 CHECK - DW32087OB4

VERMONT GAGE

2 56 UNC 2B STI HELICOIL VERMONT THREAD PLUG GAGE #2 .086 GO NO GO = .0976 .0996 - DW32086OB4

VERMONT GAGE

1 72 UNF 3B VERMONT THREAD PLUG GAGE #1 .073 GO NO GO P.D.'S = .0640 & .0659 - DW32085OB4

VERMONT GAGE

4 40 UNC 2B VERMONT THREAD PLUG GAGE #4 .112 GO NO GO P.D.'S = .0958 & .0991 - DW32084OB4

ACCU-GAGE

1/4 36 UNS 2B THREAD PLUG GAGE .25 .250 .2500 GO NO GO P.D.'S = .2320 & .2360 - DW32083OB4

M3 X .5 6H METRIC THREAD PLUG GAGE 3 0.5 GO ONLY P.D. = 2.675 INSPECTION CHECK - DW32082OB4

VERMONT GAGE

4 40 UNC VERMONT THREAD PLUG GAGE #4 .112 .1120 GO ONLY P.D. = .0958 2B OR 3B - DW32081OB4

VERMONT GAGE

NEW 1 5/8 12 UN 3B VERMONT THREAD PLUG GAGE 1.625 GO NO GO PDS= 1.5709 & 1.5766 - DW32051VTG

VERMONT GAGE

NEW 1 1/2 6 UNC 3B VERMONT THREAD PLUG GAGE 1.5 GO NO GO PD'S = 1.3917 & 1.3996 - DW32050VTG

VERMONT GAGE

NEW M33 X 2 6H VERMONT THREAD PLUG GAGE 33 2.0 GO NO GO P.D.'S = 31.701 & 31.925 - DW32049VTG
