Working Plug Gages for Checking Threaded Holes

BATH

1" 14 NF 5 THREAD PLUG GAGE 1.0 1.00 1.000 GO NO GO P.D.'S = .9536 & .9554 UNF-5 - DW32005CB4

BATH

BUDGET 7/8 9 NC 5 THREAD PLUG GAGE .875 GO NO GO P.D.'S = .8028 & .8052 UNC-5 - DW32004CB4

NORTH AMERICAN

15/16 12 UN 2B LEFT HAND THREAD PLUG GAGE .9375 GO NO GO P.D.'S = .8834 & .8908 - DW32003CB4

BATH

7/8 9 NC 5 THREAD PLUG GAGE .875 .8750 GO NO GO P.D.'S = .8028 & .8052 UNC-5 - DW32002CB4

BATH

1" 8 NC 5 THREAD PLUG GAGE 1.0 1.00 1.000 GO NO GO P.D.'S = .9188 & .9215 UNC-5 - DW32001CB4

SHOP MADE 7.472 8 AN38 LOCKNUT THREAD PLUG GAGE GO ONLY P.D. = 7.3908 AN 38 - DW32000CB4

SHOP MADE 4 5/8 12 THREAD PLUG GAGE 4.625 4.6250 4 5/8"-12 INSPECTION CHECK - DW31999CB4

SHOP MADE 1 3/8 12 LEFT HAND THREAD PLUG GAGE 1.375 L.H. 1 3/8"-12 INSPECTION - DW31998CB4

VERMONT GAGE

1 1/2 6 UNC 2B VERMONT THREAD PLUG GAGE 1.5 GO NO GO P.D.'S = 1.3917 & 1.4022 - DW31997CB4

REGAL BELOIT

1 3/4 12 UN 3B THREAD PLUG GAGE 1.75 1.750 GO NO GO P.D.'S = 1.6959 & 1.7017 - DW31996CB4

1 1/4 7 INSPECTION THREAD PLUG GAGE 1.25 1.250 1.2500 GO ONLY P.D. = 1.1572 - DW31995CB4

HEMCO

1 1/4 12 NF 2 THREAD PLUG GAGE 1.25 GO NO GO P.D.'S = 1.1959 & 1.2015 UNF-2 - DW31994CB4
