1 1/8 7 UNC 3B THREAD PLUG GAGE 1.125 1.1250 GO NO GO P.D.'S = 1.0322 & 1.0393 - DW2401RD

GF GAGE

1 3/8 6 UNC 2A THREAD RING GAGE 1.375 1.3750 NO GO ONLY P.D. = 1.2563 CHECK - DW14606AC2

GF GAGE

1 7/8 20 UN 2A THREAD RING GAGE 1.875 1.8750 GO ONLY P.D. = 1.8410 INSPECTION - DW32673CD4

GF GAGE

1/2 13 UNC 2B STI HELICOIL THREAD PLUG GAGE .5 .50 .500 NO GO ONLY P.D. = .5554 - DW32118OB4

GF GAGE

1/2 20 UNF 3A THREAD RING GAGES .5 .50 .500 GO NO GO P.D.'S = .4675 & .4643 - DW13726LVR

GF GAGE

1/4 20 UNC 2B STI HELICOIL THREAD PLUG GAGE .25 .250 NO GO ONLY P.D. = .2864 - DW32117OB4

GF GAGE

10 24 UNC 2A THREAD RING GAGES #10 .190 .1900 GO NO GO P.D.'S = .1619 & .1586 - DW2298BU

GF GAGE

3/4 16 UNF 3A SET THREAD PLUG GAGE .75 .750 .7500 GO ONLY P.D. = .7094 CHECK - DW27751RD

GF GAGE

3/4 16 UNF 3A THREAD RING GAGES .75 .750 .7500 GO NO GO P.D.'S = .7094 & .7056 - DT1480BURL

GF GAGE

3/8 16 UNC 2B TiN COATED THREAD PLUG GAGE .375 GO NO GO P.D.'S = .3344 & .3401 - DW32512CP4

GF GAGE

4 40 UNC 2B THREAD PLUG GAGE #4 .112 .1120 GO NO GO P.D.'S = .0958 & .0991 CHECK - DW10935BU

GF GAGE

6 32 UNC 2B STI HELICOIL THREAD PLUG GAGE #6 .138 GO NO GO PD'S = .1583 & .1611 - 6322BSTIP1
