MASTER GAGE

MASTER GAGE

CERTIFIED 1 1/8 7 UNC 2B THREAD PLUG GAGE 1.125 GO NO GO PD'S = 1.0322 & 1.0416 - DW28208TLC

MASTER GAGE

CERTIFIED 1" 14 UNS 2B THREAD PLUG GAGE 1.0 GO NO GO P.D.'S = .9536 & .9605 - DW26686TLC

MASTER GAGE

CERTIFIED 1" 20 UNEF 2A SET THREAD PLUG GAGE 1.0 GO NO GO PD'S = .9661 & .9616 - DW41107TLC

MASTER GAGE

CERTIFIED 1/4 20 UNC 2A THREAD RING GAGES .25 GO NO GO P.D.'S = .2164 & .2127 - DW32233TLC

MASTER GAGE

CERTIFIED 1/4 28 UNF 3A LEFT HAND SET THREAD PLUG GAGE .25 GO NOGO = .2268 .2243 - DW42420TLC

MASTER GAGE

CERTIFIED 2 56 UNC 3B THREAD PLUG GAGE #2 .086 GO NO GO P.D.'S = .0744 & .0765 - DW26168TLC

MASTER GAGE

CERTIFIED 5/16 24 UNF 3B THREAD PLUG GAGE .3125 GO NO GO P.D.'S = .2854 & .2890 - DW26285TLC

MASTER GAGE

CERTIFIED 7/16 24 UNS 2B THREAD PLUG GAGE .4375 GO NO GO P.D.'S = .4104 & .4153 - DW28214TLC

MASTER GAGE

CERTIFIED M12 X 1.25 6H THREAD PLUG GAGE 12 GO NO GO P.D.'S = .4405 & .4476 - DW28343TLC

MASTER GAGE

M11 X 1.5 6g METRIC THREAD RING GAGES 11.0 GO NO GO P.D.'S = .3934 & .3882 TOOL - DW3657RD

MASTER GAGE

M18 X 2.5 6G METRIC THREAD RING GAGES 18.0 18 GO NO GO P.D.'S = .6431 & .6363

MASTER GAGE

M25 X 1 6g METRIC THREAD RING GAGE 25 1.0 NO GO ONLY P.D. = .9526 INSPECTION - DW23858LVR
