IDEAL

IDEAL

1 1/2 18 UNEF 3B THREAD PLUG GAGE 1.5 1.50 GO NO GO P.D.'S = 1.4639 & 1.4687 - DW2409RD

IDEAL

1 5/8 16 UN 3B THREAD PLUG GAGE 1.625 1.6250 GO NO GO P.D.'S = 1.5844 & 1.5895 - DW35973BN5

IDEAL

1.114 24 UNS 2B THREAD PLUG GAGE 1.1140 GO NO GO P.D.'S = 1.0869 & 1.0924 CHECK - DW40942LVR

IDEAL

15/16 12 UN 3A THREAD RING GAGES .9375 GO NO GO P.D.'S = .8834 & .8792 CHECK - DW38999BS5

IDEAL

3 1/8 16 UN 3B THREAD PLUG GAGE 3.125 3.1250 GO NO GO P.D.'S = 3.0844 & 3.0899 - DW35518BS5

IDEAL

5 1/2 8 UNJS BEFORE PLATE THREAD PLUG GAGE 5.5 NO GO ONLY P.D. = 5.4269 - DW12150RD

IDEAL

5/16 32 UNEF 2B BEFORE PLATE THREAD PLUG GAGE .3125 GO NO GO PDS= .2972 & .3014 - DW42034BG6

IDEAL

5/8 32 UN 2B THREAD PLUG GAGE .625 .6250 GO NO GO P.D.'S = .6047 & .6093 CHECK - DW42027BG6

IDEAL

7/16 32 UN 2B THREAD PLUG GAGE .4375 GO NO GO P.D.'S = .4172 & .4216 INSPECTION - DW42032BG6

IDEAL

7/16 32 UN 3B THREAD PLUG GAGE .4375 GO NO GO P.D.'S = .4172 & .4205 INSPECTION - DW42029BG6

IDEAL

7/8 14 UNF 2B PREPLATE THREAD PLUG GAGE .875 GO NO GO P.D.'S = .8302 & .8364 - DW39608AK6

IDEAL

CERTIFIED 1/4 28 UNF 3B THREAD PLUG GAGE .25 GO NO GO P.D.'S = .2268 & .2300 - DW26198TLC
